The setup of feed pellet production line feed equipment crusher air inlet requires that the width and area of the air inlet is equal to the width and area of the feed inlet, so the sealing plate on both sides of the short feed pipe perpendicular to the centerline of the main water droplet crusher spindle should be replaced with a 12-mesh screen. The settling chamber of the feed equipment crusher should be designed as a diffusion type so that the air can pass through the conveyor with low pressure loss and low wind speed.
In addition, the depth of the settling chamber is required to be greater than 460mm so that the crushed material can settle and avoid the loss caused by the airflow carried into the dust collector. Similarly, in the design of the screw conveyor and suction pipe connection of the elbow, should pay attention to the elbow of the cross-sectional area than the cross-sectional area of the air duct is 3 to 5 times larger, in order to reduce the wind speed, to avoid the airflow to take away the material.
