Wood Shaving Machine
Tianjin Mikim Technique Co., Ltd. is one of the most experienced manufacturers and suppliers of wood shaving machine in China. If you're going to buy cheap wood shaving machine made in China, welcome to get more information from our factory. All our products are with high quality and low price.
Description
The shavings machine produced by our company can cut logs into shavings. The wood shaver, like the furniture factory, uses automatic feeding equipment, which greatly increases production speed and saves time and manpower. The shavings produced by the equipment can be adjusted to the different thickness required by various customers. Shaving thickness can be adjusted in the range of 0.1-1mm.
Parameter
|
Model |
Capacity |
Main power |
Feeding power |
Screw diameter |
Cutting power |
|
GP50 |
60-80kg/h |
11kw |
0.4kw |
φ50mm |
0.4kw |
|
GP60 |
100-150kg/h |
15kw |
0.4kw |
φ60mm |
0.4kw |
|
GP70 |
180-250kg/h |
18.5kw |
0.4kw |
φ70mm |
0.4kw |
|
GP80 |
300-350kg/h |
22kw |
0.4kw |
φ80mm |
0.6kw |
|
GP90 |
400-450kg/h |
37kw |
0.4kw |
φ90mm |
1.5kw |
|
GP120 |
0.5-0.7t/h |
55kw |
0.4kw |
φ120mm |
2.2kw |
|
GP135 |
0.8-1.0t/h |
75kw |
0.4kw |
φ133mm |
2.2kw |
|
GP160 |
1.2-1.5t/h |
90kw |
0.75-1.1kw |
φ155mm |
3.0kw |
|
GP200 |
1.8-2.0t/h |
132kw |
1.5kw |
φ195mm |
3.0-4.0kw |
The wood shaving machine is mainly used for mass production of thin shavings with uniform thickness. The finished product is the same as the shavings produced by the wood factory. The wood shaving machine adjusts the size of the finished shavings by adjusting the blade angle and the screen diameter. To adapt to various needs.
Application
Wood shavings machine is mainly used for shavings composite board, furniture manufacturing, raw materials for manufacturing wood pulp paper, household pet bedding, winter incubation breeding breeding breeding farm warm, transport fragile stuffing, prevent extrusion, etc.In addition.
